مشخصات فنی:

موتور: VOLVO  PENTA  TAD1351VE  (285kW)

سیستم انتقال قدرت:  DANA 6000

تبدیل گشتاور: DANA C9000

محور: KESSLER D106

No.

Item

Content

1

Rated buck capacity

6m³

2

Rated load

14T

3

Max scooping force

246KN

4

Max traction

324KN

5

Speed

0-25.4km/h

6

Climb uphill (full load)

≤25°

7

Max dumping height

2384mm

8

Min dumping distance

860mm

9

Max bucket lifting height

5469mm

10

Total working cycling time

14.4s

11

Turning radius

≥6932 the outer of loader


≥3283 the  inner of loader

12

Max steering angle

42.5°

13

Min ground clearance

200mm

14

Swing angle of rack

8°

15

Departure angle

16°

16

Rated power

285KW　

17

Engine

VOLVO TAD1351VE　

18

wheelbase

3642mm

19

Weight

37.8t

20

Length

10652mm


Width

2792mm


Height

2552mm
